Product Overview

Powerful PIR controller for new and existing installations.

Features:

• Total PIR switching: 2300W incandescent/halogen, 500W fluorescent/low energy plus 140W LED
• 12m detection range with 180º area of detection
• Pan and tilt feature
• Light ON times adjustable from 5 seconds to 15 minutes
• LUX (light level) adjustment – Day to Night (2 to 1000)
• Manual ON/OFF switching override
• IP55 weatherproof rating
• Simple and quick to fit terminal block connectors
• Corner mounting bracket available – SLBCB

Specifications:

• Lamp Load (W): Fluorescent/Low Energy 500, Filament 2300, LED 140
• Detection Range (Max): 12 Metres
• Angle of Detection: 180º
• Light ON Time After Last Detection (Adjustable): 5 Seconds (Min), 15 Minutes (Max)
• Permanent ON Facility: Electronic
• Adjustable Light Level Control: Yes
• EC Directives: Conforms to Latest Directives
• Dimensions: Height: 93mm x Width: 78mm x Depth: 141mm
